We are specialized in the quick PCB prototype for 1-48L FR4 PCB, 1-12L Flex PCB prototype, 2-28 Rigid-flex PCB prototype. With our 10+years experience in quick PCB prototype, you can get your PCB boards in high quality with quick lead time and low cost. Our advanced PCB technical capabilities allow us to develop and produce a top-performing PCB that meets your unique requirements.
How to get a Quote?
Method 1. Feel free to send us your files to sales@semipcb.com and let us know the quantity you need, we will check and back to you shortly. If you have special requirements, please incude them in the files or specify it in email.
Method 2. Feel free to fill the online quote form and upload the files. The quote will be provided online shortly.
Method 3. Feel free to add the Skype: Downey_PCB-PCBA, or Wechat: Downey_PCB-PCBA for quote by talking directly.
How to Order?
After quote done and you accepted it, feel free to place the order by the same way you quoted.
Method 1. If you quoted by email, please send us the email to place the order. We will send the invoice to you for payment shortly. And you will see your order very soon in your online SemiPCB account.
Method 2. If you quote online, feel free to convert the online quote to online order directly. Following the steps, you can make the payment by PayPal online or Wire Transfer offline, and we will send you the invoice by email later.
Method 3. If you quote online, feel free to send us the email to place the order, we will send the invoice to you for payment shortly.
Method 4. If you quote by Skype or Wechat, feel free to place the order by talking, we will send the invoice to you for payment shortly.
How Long for the Prototype orders?
Once you placed your PCB prototype order, our engineer will check your Gerber files to make sure it complies with our technical spec. If yes, the manufacturing will be started directly. If not, we will send you the EQ form for confirmation.
Also, if you need working files for approval before manufacturing, please let us know. But please note it may delay 1day or further and it really depends on your reply time.
Below are the lead time table for our manufacturing (it's calculated from the day of all EQ issues confirmed).
Lead Time for Quick PCB Prototype and Production | |||
| Layer | Quickest Protype Time | Standard Prototype Time | Production Time |
FR4 PCB | |||
1-2L | 24Hours | 4-6 Days | 8-10 Days |
4L | 2 Days | 6-8 Days | 10-12 Days |
6L | 3 Days | 6-8 Days | 12-14 Days |
≥8L | 4-5 Days | 8-10 Days | 14-16 Days |
Flex PCB | |||
1L | 1-2 Days | 5-7 Days | 8-10 Days |
2L | 1-2 Days | 5-7 Days | 8-10 Days |
4L | 3-4 Days | 8-10 Days | 10-12 Days |
6L-16L | 6-8 Days | 12-14 Days | 14-18 Days |
Rigid-Flex PCB | |||
2L | 5-7 Days | 10-12 Days | 12-14 Days |
4L | 6-8 Days | 12-14 Days | 14-16 Days |
6L-28L | 8-10 | 14-16 Days | 16-18 Days |
Our PCB boards are highly used in computer, communication network equipment, mobile phone, digital camera, instrumentation, aerospace instrument, biomedical, home appliance and lighting, drone, smart wear, smart home, bluetooth, car, industrial control, robot, tablet, LCD, projection Instrument, car navigation, security and other high-tech fields, etc.
Below are our short & quick capabilities for your reference.
PCB Capabilities Short List
| Layer | 1-48Layers |
| PCB Material | Rigid PCB Material: FR4 TG 130 - FR4 TG 180, Rogers, Aluminum, Copper core, Rogers, etc.
Flex PCB Material: PI, PET, Super-thin FR4, etc. |
| Minimum Track width/space | Rigid PCB: 0.078mm/0.078mm
Flex PCB: 0.035mm/0.035mm |
| Blind/Buried Vias | Yes |
| Minimum holes size | Rigid PCB: 0.1mm Flex PCB: 0.025mm |
| Surface Finish | HASL, Immersion Gold (ENIG), Immersion Tin, Immersion Silver, OSP, ENEPIG, Hard Gold Plating |
PCB Assembly Capabilities Short List
| Quantity | From prototype to mass production (No MOQ and no limit) |
| Assemble Types | SMT, THT, Hybrid, Single side or both sides Available for Rigid PCB, Flex PCB and Rigid-Flex PCB |
| Parts Procurement | Full Turnkey (We provide all parts) |
| Partial Turnkey (Customer provide some parts, and we provide the rest) | |
| Kitted (Customer provide all parts) | |
| Components Package | 01005, 0201, BGA, QFN, QFP, etc. |
| Test | Visual Inspecction, AOI, X-Ray, ICT, FCT, etc. |
| Other Services | IC Programming, Box Build, PCBA copy, Injection Molding, CNC, etc. |
